  ln the elevator car, fixed limit devices are installed on the left and right sides of the floor, and retractable limit devicesare installed near the front door to prevent the car from scratching to the elevator.



  Features Of ATLAS-WT3 commercial freight elevator



  Automobile Limiting Device In Car.



  Landing Floor Call Elevator Device.



  Specification Of ATLAS-WT3 Freight Elevators

  NO. Specification ATLAS-WT3

  1 Capacity (kg) 2000 2500 3000

  2 Speed (m/s) 0.5 1 0.5 1 0.5 1

  3 Operation System full collective selection operation

  4 Driving System VVVF

  5 Door Operator System VVVF

  6 Traction Machine Permanent Magnet Synchronous Gearless type

  7 Control System CTRL80

  8 Car Dimension mm

  width*depth 1800×2300 2000×2500 2300×2500



  9 Shaft Size mm

  W*H 3000×2700 3300×2900 3600×2900



  For more information about elevators types, please feel free to contact us!
